PVC co-extruded foam board uses pvc as inner foam, the outside is also pvc veneer, so the density and hardness is larger and higher than plate made with other materials. The smooth surface of the expanded PVC sheet can be used for screen printing, painting, cut mounting, gluing, engraving, lapping.
Features:
1) Light-weight, easy storage and processing, smooth and rigid surfaces
2) Sound & heat insulation , noise absorption, not easy to scratch
3) waterproof, Antiflaming and self-extinguishing,Moisture-resistant
4) Easy fabrication with conventional tools, such as blades, saws, hammers and drills.
5) Flat surface applicable to screen printing, painting, mounting.
Bonding together with other PVC products by PVC adhesives
6) Suitable for thermal shaping, thermal bending and fold processing.
Applications:
1) Wall and ceiling cladding
2) Partitions
3) Shop outfitting
4) Point of sale
5) Signage
6) Fabricated displays
7) Exhibition stands
Technical Data:
Model Number | ES-PFB |
Size | 1220x2440mm |
Density | 0.5g/cm3—0.9g/cm3 |
Thickness | 1-20mm |
Tolerances | 1) ±5mm on width. 2) ±10mm on length. |
Color | White |
Water Absorption % | 0.19 |
Tensile strength at Yield Mpa | 19 |
Elogation at break % | > 15 |
Flexual Modulus Mpa | > 800 |
Vicat Softening point °C | ≥70 |
Dimensional stability% | ±2.0 |
Screw holding strength N | > 800 |
Choppy Impact Strength KJ/m2 | > 10 |
